Magnat Signature IWT 162 (Pair)

Key Features

• High-end chassis technology with ceramic/aluminum bass-midrange drivers and a coated fabric dome
• High load capacity with compact dimensions
• Uncomplicated installation thanks to a sophisticated mounting system
• Tonal structure perfectly coordinated with the Signature series, therefore can be individually combined
• Treble level can be adjusted in 3 stages

 Highlights

• Designed for installation in drywalls (no housing required) or in closed volumes (30 liters or more)
• 6fold clamping mechanism for very easy and robust installation in surfaces of up to 30 mm thickness
• Elaborate phase-optimized crossover with 3 settings for the tweeter level
• Woofer-midranges with magnet protection cover to prevent any damage and undesirable background noise
• Durable long-throw rubber surrounds for linear operation of the woofer-midrange drivers to handle even large cone excursions
• Gold-plated push terminals for cables with cross-sections of up to 6 mm²

Product Specifications

PRINCIPLE – 2-way in-wall/in-ceiling loudspeaker

DRIVERS – 1 x 6.5“ woofer-midrange,1 x 1“ dome tweeter

POWER HANDLING (RMS/MAX.) – 110 / 180 watts

SENSITIVITY (2.8V/1M) – 91 dB

IMPEDANCE – 4 Ohms

FREQUENCY RESPONSE – 32 – 28000 Hz

CROSSOVER FREQUENCIES – 3.100 Hz

RECOMMENDED AMPLIFIER OUTPUT – 20 – 180 Watts

MOUNTING DEPTH- 102 mm

OUTER DIMENSIONS (WXH) – 220 x 320 mm

CUTTING OUT (WXH) – 186 x 286 mm

WEIGHT – 2.15 kg
